1 – Steam Boiler.
2 – Economizer.
3 – Chimney.
4 – Electrical Control.
5 – Water Treatment.
6 – Condensate Vessel.
7 – Under pressure degassing unit.
8 – Feeding Pumps.
9 – Modulating Water Feeding.
10 – Blow Down.
11 – Mixing cooler.
12 – Flash Steam Recuperator.
13 – Sampling Cooler.
14 – Electronic Boiler and Plant Control.
15 – Distance System Control (PC, FAX, SMS). |
